Specifications/Properties
Interlock Width
1 3/16 in / 30 mm
max. Panel Height
20 ft / 6,000 mm
max. Panel Width
20 ft / 6,000 mm
max. Panel Weight
1,650 lbs / 750 kg
max. Panel Area
150 sqft / 14 sqm
max. IGU Thickness
up to 1 9/16 in / 40 mm
Thermal
0.31
Sound
STC 42
Water Penetration
Class 8a
Air Tightness
Class 4
Wind Tightness
C5
Light Transmission
96%
